180 degree UTP toolless keystone jack simplifies installation with a punch-free design. The 180 degree punch-down field of view is clear, and the unshielded structure is suitable for low-interference environments, meeting daily network termination needs.
180 degree UTP toolless network keystone jack complies with applicable communication standards. Its unshielded construction is ideal for low-interference environments such as homes and offices. The punch-free design allows for quick, tool-free termination, and the 180 degree punch-down field of view provides a wide, easy-to-use interface. Compatible with 22-26AWG cables, it features a UL94V-0 flame-retardant PC body and gold-plated contacts for oxidation resistance. It can be used in wall sockets and patch panels, ensuring stable network transmission.
Specifications
ModelNT-K011B
CategoryCat6
/Cat6a
/Cat7
Shielding TypeUTP
Gold Plating3U-50U gold plating
IDC/
Applicable Wire Gauge22-26 AWG
Wire Termination Angle180 degree
Voltage rating150 Volts
Current Rating1.5AMP
Contact resistance20 m-ohm
Insulation Resistance500M-ohm
Dielectric Withstand Voltage1000 V AC RMS, 60Hz 1min
